The fixed hydraulic bridge is a cargo handling and auxiliary equipment used in conjunction with the warehouse.
(1) The height of the boarding bridge can be adjusted according to the height of the truck compartment.
(2) the use of hydraulic power, equipped with high-performance components, safe and reliable.
(3) table with pattern steel plate, with good anti-skid performance.
(4) professional safety details designed to maximize safety factor.

Fixed hydraulic boarding table specification table
Number	Model	Rated  load (kg)	Lift  Itinerary (mm)	Minimum  Height (mm)	Table  size	Lip  Width	Lifting  Time (s)	Motor  Power  (kw)	Voltage  (v)
					(mm)	(mm)
1	DCQ6-0.55	6000	+350,-200	590	2000X2000	400	20	0.75	AC-380V
2	DCQ6-0.7	6000	+400,-300	590	2500X2000	400	20	0.75	AC-380V
3	DCQ10-0.55	10000	+350,-200	590	2000X2000	400	20	0.75	AC-380V
4	DCQ10-0.7	10000	+400,-300	590	2500X2000	400	20	0.75	AC-380V
